– is the maximum permissible weight of the unit when fully loaded.
It includes all weights, inclusive of all fluids, cargo, optional equipment and accessories.
For safety and product performance do NOT exceed the GVWR.
GCWR (Gross Combined Weight Rating) - Is the maximum permissible loaded weight of your motor home and any towed trailer or towed vehicle.
Actual GCWR of this vehicle may be limited by the sum of the GVWR and the installed hitch receiver maximum capacity rating;
see hitch rating label for detail.
GAWR (Gross Axle Weight Rating) - is the maximum permissible weight, including cargo, fluids, optional equipment and accessories that can be safely supported by each axle.
UVW (Unloaded Vehicle Weight)* - is the typical weight of the unit as manufactured at the factory.
It includes all weight at the unit’s axle(s), including full fuel, all fl uids and LP Gas.
The UVW does not include cargo, fresh potable water, additional optional equipment or dealer installed accessories.
*Estimated Average based on standard build optional equipment.
CCC (Cargo Carrying Capacity)** - is the amount of weight available for fresh potable water, cargo, passengers, additional optional equipment and accessories.
CCC is equal to GVWR minus UVW.
Available CCC should accommodate fresh potable water (8.3 lbs per gallon).
Before fi lling the fresh water tank, empty the black and gray tanks to provide for more cargo capacity.
**Estimated Average based on standard build optional equipment.
Each Forest River RV is weighed at the manufacturing facility prior to shipping. A label identifying the unloaded vehicle weight of the actual unit and the cargo carrying capacity is applied to every Forest River RV prior to leaving our facilities.
The load capacity of your unit is designated by weight, not by volume, so you cannot necessarily use all available space when loading your unit.
Actual towing capacity is dependent upon your particular loading and towing circumstances, which includes the GVWR, GAWR and GCWR as well as adequate trailer brakes. Please refer to the Operator's Manual of your vehicle for further towing information.
20RBRam Pro Master 3500Features & Options
RAM Pro Master 3500 3.6L V6, 24 valve engine/280 (HP)
Sumo Spring front and rear suspension
24-Gallon fuel tank
Solid hardwood cabinetry (Not found on Pro Master competition)
Rockwool R-15 insulation (Best insulated of any Pro Master)
Imported European dual pane acrylic windows with solar reflective exterior pull-downs
Truma Combi Eco Plus furnace/water heating system
NEW Truma Aventa 13.5K BTU A/C (3 Speeds, Dehumidifier and Night Mode)
Firefly Multiplex, 2,000W Xantrex inverter with Auto Gen Start
3 Group 31, 115AH AGM Batteries (345AH total)
220W Solar (Dual 110W panels)
Fresh tank and black tank above floor to protect water lines
Sure Level Tank Sensors read tank levels at 10% increments
Fiberglass shower vs. competitor’s ABS shower
Residential high rise faucet and sink
Lagun table (Rear), removable table (Front)
Marine grade PVC vinyl with 3/8” foam backer
Nova Kool refrigerator
MaxxAir Fan with rain sensor and remote
Roof rack with ladder
NEW 24” LED Smart TV
King Olympus Wi-FI Router, Digital Antenna, and Cell Booster Prep
NEW 30AMP Smart Plug (LED light power indicator, 20X contact area, weatherproof)
Q-Foam in sofas, jumpseat and twin beds
New Larger Square Sink w/ Pull out Sprayer Faucet
Pop Top w/190W Solar Panel, Coleman Mach 10 NDQ A/C,
Skylight and Thule Awning
Extra 630AH Lithionics Lithium Battery /w Internal Heater (1260AH Total w/ Li3 Lithium Option) (Must Have Optional Li3 Lithium Battery System)
Cozy Wrap® upgraded insulation
Li3 Lithium Battery System includes: 630 amp-hour lithium battery with internal heater, Bluetooth battery management system and remote LCD display, second under hood alternator with multi-stage voltage regulator, Xantrex XC Pro 3,000W inverter/charger with Bluetooth XC Remote, Xantrex Echo-charge (Charges chassis battery while plugged into shore power). Onan Generator not included with Li3 Lithium Battery option.
